TRANSITION BRIDGES TYPE-MP
Crossing bridges (Change ladders) are designed to provide safe access to road and rail tanks in order to perform loading and unloading operations, inspection, sampling, etc.

According to the principle of operation, the transition bridge is a structure consisting of a parallelogram mechanism with hinged steps, due to which the steps always remain in a horizontal position.

Two spring-type shock absorbers serve as a balancing mechanism for the transitional bridge.

In the garage position on the flyover, the MP bridge handrails are in a vertical position and are held by a latch (garage position lock).

If it is necessary to maintain the tank along the entire length, the transitional bridge is equipped with a special mechanism (MTP longitudinal movement mechanism), which allows free movement along the entire overpass.

For safety during the operation of the bridge with MPP, guardrail posts or rotary guardrails are installed.

The intrinsic safety of the product is achieved through the use of intrinsically safe materials (copper, brass, polyamide) in friction pairs.

Bridges are made in intrinsically safe design, which allows them to be used in hazardous areas.

You can buy transitional bridges MP/MP-A from us (Changeover ladder).

Options for bridges by the number of steps:

  • Transition bridge MP-2 - 2 steps
  • Transition bridge MP-3 - 3 steps
  • Transition bridge MP-4 - 4 steps
  • Transition bridge MP-5 - 5 steps
  • Transition bridge MP-6 - 6 steps
BRIDGE TRANSITION MP-A
BRIDGE TRANSITION MP-A-MPP
Peculiarities:

  • Fastening to the overpass with a special mechanism for free movement along the overpass;

  • Balancing the bridge with a spring compensator;

  • Fixing in garage and working positions;

  • Intrinsically safe execution;

  • Possibility of using a garage position sensor;

  • Galvanized especially resistant to corrosion steps;

    • Possibility of installation of additional protective protections.
STAINLESS STEEL BRIDGES
TRANSITION BRIDGE MP-A-NZH
Peculiarities:

  • The structure is made of corrosion-resistant steels resistant to aggressive products.

  • Fastening to the flyover is stationary or with a special mechanism for free movement along the flyover;

  • Balancing the bridge with a spring compensator;

  • Fixing in garage and working positions;

  • Possibility of using a garage position sensor;

  • Possibility of installation of additional protective protections.
